OBDSTAR is introducing a major software upgrade that adds Locked Bosch MG1/MD1 ECU Read/Write And Unlock support. The update supports multiple Bosch MG1/MD1 ECUs across BMW, FCA, Ford and ISUZU applications, with internal flash/EEPROM read & write, ECU unlock, and checksum verification. This function is available on OBDSTAR X300 Classic G3, DC706, and ECU MASTER.
Supported Models
| ECU Model | Application | Chip |
|---|---|---|
| Bosch MD1CP032 | BMW B57 | TC299 |
| Bosch MG1CS024 | BMW B48/B58 | TC298 |
| Bosch MG1CS201 | BMW B48/B58 | TC298 |
| Bosch MD1CS069 | FCA | TC299 |
| Bosch MD1CP006 | Ford | TC298 |
| Bosch MD1CS089 | ISUZU etc. (Only for ECU MASTER C) | TC299 |
| More models | Coming soon | — |
Supported Devices & Accessories
- Supported Devices:
- Required Adapter: RH850/V850 ADAPTER KIT (C4-06 adapter)
Functions
- Read internal flash
- Write internal flash
- Read internal EEPROM
- Write internal EEPROM
- ECU unlock
- Checksum verification
Why This Update Matters
The new solution allows technicians to complete locked MG1/MD1 ECU read/write and unlock directly at the workshop without sending the ECU away. It is compatible with the RH850/V850 Adapter, supports both PCs and tablets, and requires only minimal capacitor/resistor removal with standardized wiring—only two boot wires need to be soldered, while the adapter automatically adapts the required unlock parameters.
Note: Software updates may vary depending on product configuration.
